Pass PVIP Exam with Updated PVIP Exam Dumps PDF 2025

PVIP Exam Dumps – Free Demo & 365 Day Updates

NABCEP PVIP (PV Installation Professional) Board Certification Exam is a rigorous and comprehensive exam designed to assess the knowledge, skills, and abilities of individuals who install solar photovoltaic (PV) systems. NABCEP, or the North American Board of Certified Energy Practitioners, is a non-profit organization that aims to promote the use of renewable energy and establish professional standards for energy practitioners. The PVIP certification is one of the most highly regarded credentials in the solar industry, and passing the exam is a significant achievement for any solar professional.

NEW QUESTION 23
A ground resistance measurement on a newly installed grounding electrode indicates a resistance of 130#. The earth connection may be improved by connecting the existing electrode to a:

Supplemental grounding electrode located 5 ft, away.

Supplement ¼ in, in thick aluminum plate electrode buried 30 in. down and located 7 ft, away.

Supplemental copper plated steel grounding electrode located 8 ft, away.

Buried water piping system using 40 ft. of 2 in. PVC piping located 10 ft awat.

NEW QUESTION 24
A PV module has a NOCT of 47°C. At 1000 W/m² and 35°C ambient, what is the cell temperature?

47°C

55°C

59°C

63°C

NEW QUESTION 25
Inspection of a new PV installation shows that the dwelling uses a galvanized water pipe for its grounding electrode and that the PV system now shares the connection. Which of the following is an acceptable supplemental electrode method to ensure the integrity of having a grounding electrode?

Connecting the water pipe to the service entrance panel metal structure

Connecting the water pipe to a gas pipe that is known to be solidly grounded

Connecting the service panel to an auxiliary ground used by a lightning protection system

Connection the service panel to a copper-clad steel ground rod near the panel

NEW QUESTION 26
A 20 kW system has a measured output of 18 kW at STC. What is the total system loss?

10%

15%

20%

NEW QUESTION 27
Which of the following MUST be referenced for determining a site’s design wind speed?

The NEC version in effect

The jurisdiction’s local building code in effect

The ASHRAE Handbook_fundamentals in effect

The module manufacture’s design wind speed

NEW QUESTION 28
A module’s Voc is 40V at STC. At -5°C with a coefficient of -0.33%/°C, what is the Voc?

42.0V

43.0V

44.0V

45.0V

NEW QUESTION 29
A PV module is mounted with a 2-inch standoff from a shingle roof. What is the minimum clearance required for fire access per the International Fire Code (IFC)?

1 inch

3 inches

6 inches

9 inches

NEW QUESTION 30
A homeowner is concerned that a 6kWdc PV system might be experiencing a performance issue. The homeowner has noticed what appears to be declining production. The installer analyzes the following data acquisition system (DAS) results for each year since the installation:

Given the data, which is the MOST likely conclusion to draw?

The system has experienced above-average degradation and a module warranty claim should be explored.

A combination of normal module degradation combined with cloudy weather has caused lower output in the past few years.

There is a problem with the DAS because the peak sun hours do not correlate with production values and the das should be repaired.

There is an intermittent inverter failure that is causing production to be lower than expected and the inverter should be repaired.

NEW QUESTION 31
Thermal imaging infrared cameras can be used to help find which of the following system operational issues?

Intensity of solar insolation to determine power output

Battery state of charge in a multimode system

Blind spot fault in a source circuit

Loose PV input circuit terminations in a combiner box

NEW QUESTION 32
A project is using a PV module with a 25-38dc maximum power voltage range and a single input inverter with an operating windows of 250vdc-450dc. The dwelling the system is to be installed on has a 5:12 roof with a southeastem face that can accommodate 14 modules and southwestern face that can accommodate 10 modules.
What is the MAXIMUM number of modules that can be installed for proper inverter maximum power point tracking?

NEW QUESTION 33
When performing a system checkout after completing the installation, what is the SAFEST sequence of tasks to detect installation errors before closing any disconnects to the inverter, charge controller, or batteries?

Perform visual inspection, check polarity and measure open-circuit voltage.

Perform visual inspection, install source circuit fuses, and measure open-circuit voltage.

Perform visual inspection, install source circuit fuses, and measure open-circuit current.

Install source circuit fuses, verify that all equipment-grounding conductors are secure, and measure ac line voltage.

NEW QUESTION 34
Insulation resistance testing is being performed on the conductors of a 3-year-old PV system. With a constant high test voltage being applied to a dc conductor, the test results in a high resistance reading. Which does this finding indicate?

Wiring insulation has degraded and is resulting in leakage.

Soling of modules has reduced the efficiency of the system.

Typical module degradation has lowered the output of the system’s strings.

The conductor insulation is functioning as intended.

NEW QUESTION 35
A PV connection is being made at the center of a 300 ft. long 200 feeder. See the attack diagram. The feeder originates in the upper third of the 800A main service panel (800A main breaker) with a 200A breaker and terminates in a 200A main-lug-only subpanel. The rated output of the PV system inverter is 100A.

Which are the NIMUMUM actions required to achieve an NEC-compliant installation?

Install a 325A breaker at the PV source connection point on the portion of the feeder toward the subpanel. Increase the capacity of the feeder from the main panel board to 325A breaker to the bottom of the main service panel, away from the 800 main breaker.

Install a 325A at the PV source connection point on the portion of the feeder toward the subpanel, increase the capacity of this portion of the feeder to 325A, add a 200A main breaker to the subpanel, and move the 200A breaker to bottom of the main service panel, away from the 800A main breaker.

Install a 200A breaker at the PV source connection point on the portion on the portion of the feeder toward the subpanel and move the 200A breaker to the top of the main service panel, adjust to the 800A main breaker.

Install a 200A breaker at the PV source connection point on the portion of the feeder toward the subpanel, maintain the capacity of the entire feeder, and move the 200A breaker to the bottom of the main service panel, away from the 800A main breaker.

NEW QUESTION 36
A ground resistance measurement on a newly installed grounding electrode indicates a resistance of 130. The earth connection may be improved by connecting the existing electrode to a:

Supplemental grounding electrode located 5 ft, away.

Supplement 1/4 in, in thick aluminumplate electrode buried 30 in. down and located 7 ft, away.

Supplemental copper plated steel grounding electrode located 8 ft, away.

Buried water piping system using 40 ft. of 2 in. PVC piping located 10 ft awat.

NEW QUESTION 37
A PV system is located at 41 N latitude. The sun angle is 23 on December 21 at solar noon. Assuming that the
65 ft tree is directly south of the PV array and will grow 20 ft. over the life of the PV system, what is the MNIMUM distance the tree to the button of the prevent shading?

98 ft.

153 ft.

167 ft.

201 ft.

NEW QUESTION 38
A PV connection is being made at the center of a 300 ft. long 200 feeder. See the attack diagram. The feeder originates in the upper third of the 800A main service panel (800A main breaker) with a 200A breaker and terminates in a 200A main-lug-only subpanel. The rated output of the PV system inverter is 100A.

Which are the NIMUMUM actions required to achieve an NEC-compliant installation?

Install a 325A breaker at the PV source connection point on the portion of the feeder toward the subpanel. Increase thecapacityof the feeder from the main panel board to 325A breaker to the bottom of the main service panel, away from the 800 main breaker.

NEW QUESTION 39
A PV array’s tilt is 30° at a latitude of 40°N. What is the winter energy loss compared to optimal tilt?

5-10%

10-15%

15-20%

20-25%

NEW QUESTION 40
A PV system is installed in a location with an average annual ambient temperature of 30°C. If the module’s NOCT (Nominal Operating Cell Temperature) is 45°C, what is the expected cell temperature under standard operating conditions (800 W/m² irradiance)?

45°C

50°C

55°C

60°C

NEW QUESTION 41
A module’s STC power is 300W, with a temperature coefficient of -0.40%/°C. At 65°C, what is the power loss percentage?

12%

14%

16%

18%

Loading …

The PVIP Board Certification is recognized throughout the solar industry as a mark of excellence and is often required by employers and project owners. It is also a key credential for professionals seeking to advance their careers or specialize in certain areas of PV installation.
