Explanation
Automation is one of the key features of GMPLS that allows dynamic provisioning of optical transport connections between IP routers and optical network elements2. Automation reduces the operational time and administrative overhead required to provision new connectivity, which in turn reduces the operational expenditure (OPEX) of the network. Reducing CAPEX, providing resilience against multiple failures, and supporting multi-vendor networks are not direct benefits of automation, but rather possible outcomes of using GMPLS in general. References:
* 1: Nokia GMPLS-controlled Optical Networks Course | Nokia
* 2: GMPLS – Nokia
* 3: Traffic survivability through Protection and Restoration Combined (PRC) – YouTube
* [4]: GMPLS: Architecture and Applications – Google Books

Explanation
The Commissioning File in GMRE nodes is a file with target values that determine whether a given LSP is possible. The Commissioning File contains parameters such as power, OSNR, Q-factor, and dispersion that are used to evaluate the feasibility of an LSP request. The Commissioning File is generated by the Network Planning Application (NPA) based on the network design and optical impairments. The Commissioning File is uploaded to each GMRE node and is used by the CSPF algorithm to find a suitable path for the LSP. References : Nokia GMPLS-controlled Optical Networks Course | Nokia, Network Planning Application (NPA) | Nokia

Explanation
The Feasibility File is a file that contains a set of target values for various optical impairment parameters, such as OSNR, CD, PMD, and PDL, that are used to determine whether a given LSP can be routed through the GMRE network. The Feasibility File is generated by the Network Planning Application (NPA) based on the network design and the service requirements. The Feasibility File is then loaded into the GMRE nodes and used by the GMPLS routing engine to perform feasibility checks for LSP requests. The Feasibility File ensures that the LSPs are routed in accordance with the network plan and the optical performance criteria12.
References:
* 1: Nokia GMPLS-controlled Optical Networks Course | Nokia
* 2: GMPLS – Nokia

Explanation
The SNC Nominal Route is the default or preferred route that is assigned to an LSP when it is created. The SNC Nominal Route is determined by the constraints that are specified by the user during the LSP creation process, such as cost, SRLG, color, bandwidth, protection, and regeneration. The user can modify the SNC Nominal Route in NFM-T by using the Constraint Wizard, which is a tool that allows the user to change the constraints for an existing LSP. The Constraint Wizard will then compute a new SNC Nominal Route based on the modified constraints and update the LSP accordingly34. References:
* 3: Nokia GMPLS-controlled Optical Networks Course | Nokia
* 4: Nokia Network Functions Manager for Transport User Guide | Nokia

Explanation
A Label Switched Path (LSP) is the path created by MPLS nodes that use labels to forward packets across the network. A label is a short identifier that is attached to each packet and indicates the next hop or destination of the packet. The nodes use a label forwarding table to switch packets based on their labels, without inspecting the packet headers. This can improve the performance, security, and quality of service of the network. An LSP can be established by using GMPLS protocols such as OSPF-TE and RSVP-TE, which exchange information about the network topology, resources, and constraints. References : Nokia GMPLS-controlled Optical Networks Course | Nokia, GMPLS – Nokia

Explanation
To configure the Trail template in NFM-T for an Uplink board (such as 2UC400) in a network with only LI restoration capability, you need to check the Logical Link box, set the Port Type to Unterminated, uncheck the ASON Routed box, and uncheck the ASON Tunnel box. This configuration allows you to create a logical link between two Uplink boards that can be used for LI restoration. The logical link is not terminated at the Uplink board, but at the OTU board. The ASON Routed option is not needed for LI restoration, as the LSPs are established by NFM-T and not by GMPLS. The ASON Tunnel option is not applicable for Uplink boards. References : Nokia Advanced Optical Network Management with NFM-T Course | Nokia, Nokia 1830 PSS-4, PSS-8, PSS-16 and PSS-32 Platforms – NATO

Explanation
The OSPF-TE protocol is an extension of the Open Shortest Path First (OSPF) protocol that is used to exchange information about the state of links in a GMPLS network. OSPF-TE advertises link attributes such as bandwidth, latency, priority, protection, or switching capabilities to other nodes in the same area. OSPF-TE enables nodes to build a Traffic Engineering Database (TED) that contains the topology and resource information of the network. OSPF-TE helps nodes to perform CSPF calculations and establish LSPs using RSVP-TE signaling. References : Open Shortest Path First – Wikipedia, Understand Open Shortest Path First (OSPF) – Design Guide, RSVP-TE and OSPF-TE extensions for GMPLS

Explanation
The label on the top of the MPLS label stack is swapped at an intermediate node. This is because the top label is the one that is visible to the node and determines the forwarding decision. The node looks up the top label in its label forwarding table and swaps it with a new label that corresponds to the next hop or destination. The node then forwards the packet to the next node, which repeats the same process. The bottom label is only used to indicate the end of the label stack and is not swapped. References : [Nokia GMPLS-controlled Optical Networks Course | Nokia], [MPLS Label Stack – Nokia]

Explanation
Constrained Shortest Path First (CSPF) is an extension of the shortest path first (SPF) algorithm that is used to find the best path for a Label Switched Path (LSP) in a GMPLS network. CSPF takes into account additional constraints such as bandwidth, latency, priority, or node or link inclusion or exclusion. CSPF works by pruning those links that do not meet the specified constraints and then applying the SPF algorithm to the remaining links. This way, CSPF can find a path that satisfies both the shortest distance and the constraints. References : Constrained Shortest Path First – Wikipedia, Constrained Shortest Path First (CSPF) – Metaswitch

Explanation
Signaling protocols are protocols that are used by the ingress router to set up a new LSP in an MPLS network.
Signaling protocols are responsible for requesting, allocating, and releasing resources along the LSP, as well as establishing and maintaining the label bindings between the nodes. Some examples of signaling protocols are RSVP-TE, LDP, and CR-LDP34. References:
* 3: Nokia GMPLS-controlled Optical Networks Course | Nokia
* 4: MPLS Configuration Guide for Cisco NCS 5500 Series Routers, IOS XR Release 7.1.x – Implementing MPLS Label Distribution Protocol [Cisco IOS XR Software (End-of-Sale)] – Cisco

Explanation
A network with ROADM GMPLS nodes and optical transponder connections could have both L0 and L1 restoration capabilities. L0 restoration refers to the ability of the network to recover from failures at the optical layer, such as fiber cuts or node failures, by rerouting the affected LSPs to alternative paths at the same layer.
L0 restoration can be achieved by using GMPLS signaling protocols, such as RSVP-TE or CR-LDP, to establish backup LSPs in advance or on demand. L0 restoration can provide fast recovery times and high availability for optical services34. L1 restoration refers to the ability of the network to recover from failures at the sub-wavelength layer, such as transponder failures or wavelength unavailability, by rerouting the affected LSPs to alternative paths at a higher layer. L1 restoration can be achieved by using GMPLS routing protocols, such as OSPF-TE or ISIS-TE, to advertise the sub-wavelength information and availability to other nodes in the network. L1 restoration can provide more flexibility and efficiency for sub-wavelength services56.
References:
* 3: GMPLS – Nokia
* 4: Generalized Multi-Protocol Label Switching – Wikipedia
* 5: Sub-Wavelength Switching – Nokia
* 6: Sub-Wavelength Switching in Optical Networks – IEEE Xplore

Explanation
Quality of Service (QoS) in GMPLS is the ability to set constraints such as latency and priority for different kinds of services. This means that GMPLS can allocate network resources according to the specific requirements of each service, such as voice, video, or data. For example, a voice service may need low latency and high priority, while a data service may need high bandwidth and low priority. GMPLS can use Traffic Engineering (TE) extensions to OSPF and RSVP protocols to advertise and reserve network resources based on QoS parameters. References : [Nokia GMPLS-controlled Optical Networks Course | Nokia], [Quality of Service – Nokia]

Explanation
The GMRE node address is the IP address for communication between network elements (NEs) in a GMPLS-controlled optical network. The GMRE node address is also known as the GMRE loopback address or the GMPLS node IP. It is used by GMPLS protocols such as LMP and RSVP to identify and communicate with other GMRE nodes. The GMRE node address is configured on each NE and is advertised by OSPF-TE to other nodes in the same area. References : Nokia 1830 PSS-4, PSS-8, PSS-16 and PSS-32 Platforms – NATO, 1830 PSS Identifiers

Explanation
Test Mode is a feature of the Link Management Protocol (LMP) that allows testing the connectivity and functionality of a link or a TE-link. Test Mode can be initiated by either end of a link or a TE-link by sending a Test Message with a Test ID and a Test Pattern. The Test Message is sent over the control channel of the link or the TE-link and contains information such as the source and destination IP addresses, the link ID, and the test parameters. The receiving node then verifies the Test Message and sends back a TestStatusAck message with the same Test ID and Test Pattern. The TestStatusAck message indicates whether the test was successful or not, and if not, what was the reason for failure. Test Mode can be used to check if a link or a TE-link is operational, if it has any errors or faults, or if it supports certain features or capabilities. References : Nokia GMPLS-controlled Optical Networks Course | Nokia, RFC 4204 – Link Management Protocol (LMP)

Explanation
The GMRE notify address is an IP address used to signal failures on downstream nodes upstream to the head node. The GMRE notify address is configured on each GMRE node and is used to send a Notify message to the head node when a failure occurs on a link or node alongthe LSP. The Notify message contains the failure information and the LSP ID. The head node can then initiate a restoration process based on the Notify message. References : Nokia GMPLS-controlled Optical Networks Course | Nokia, GMPLS – Nokia

Explanation
To configure the Trail template in NFM-T for an Uplink board (such as 2UC400) in an MRN network with LO and LI restoration capabilities, you need to check the Logical Link box, set the Port Type to Unterminated, check the ASON Routed box, and uncheck the ASON Tunnel box. This configuration allows you to create a logical link between two Uplink boards that can be used for LO or LI restoration. The logical link is not terminated at the Uplink board, but at the OTU board. The ASON Routed option enables the GMPLS control plane for the logical link, while the ASON Tunnel option is not applicable for Uplink boards. References : Nokia Advanced Optical Network Management with NFM-T Course | Nokia, Nokia 1830 PSS-4, PSS-8, PSS-16 and PSS-32 Platforms – NATO
